Fanimation TR305 16-Speed Reversing DC Motor Ceiling Fan & Light Handheld Remote Control – Fresh Air, CCT Select, Home Away & Dimming for Kute & Other Fanimation DC Fans
Fanimation TR305 16-Speed Reversing DC Motor Ceiling Fan & Light Handheld Remote Control – Fresh Air, CCT Select, Home Away & Dimming for Kute & Other Fanimation DC Fans
SKU: Fanimation-TR305
- Special features
240* available with the manufacturer as of yesterday
Add $100.00 more to your cart for free shipping!*
Couldn't load pickup availability
More from the collection
-
Fanimation TR305S 16-Speed Reversing DC Motor Ceiling Fan & Light Handheld Remote Control – Fresh Air, CCT Select, Home Away & Dimming for Radius, Kindred, EightyFour, Blitz & Other Fanimation DC Fans
Regular price $40.48Regular price$44.98Sale price $40.48 -
Fanimation TR500S 3-Speed Ceiling Fan & Light Handheld Remote Control with Dimming for All-Weather Pylon, Aire Drop & Vintere Fans
Regular price $34.98Regular price
Fan Controls Compatibility Table
Compatible AC fans may also support select optional controls such as WC2WH 3-Speed Fan & Light Wall Control with Rocker Switch and Dimming for Most Fanimation AC Ceiling Fans, WR501WH 3-Speed Fan and Light Wall Remote Control with Canopy Receiver for Most Fanimation AC Ceiling Fans, and fanSync BTCR9 Bluetooth Receiver and Handheld Remote for Most 3-Speed Fanimation AC Ceiling Fans with Lights where specified on the fan’s product page or specification sheet.
Description
Downloads
Want a discount?
Return Policy
Need Installation
Fanimation TR305 16-Speed Reversing DC Motor Ceiling Fan & Light Handheld Remote Control – Fresh Air, CCT Select, Home Away & Dimming for Kute & Other Fanimation DC Fans
Brand: Fanimation
Product Description
This Fanimation TR305 handheld remote control is designed for use with compatible Fanimation DC-motor ceiling fans originally equipped with a TR305 remote-control system. Confirmed application: Kute (16-Speed), along with other Fanimation DC fans whose specification sheets identify TR305 as the included remote. Fanimation's own current documentation for Spitfire DC shows an inconsistency between TR305 and TR360 as the included control — if you have a Spitfire DC fan, confirm the exact remote model against your fan's specification sheet or owner's manual before ordering.
The remote provides 16 fan speeds, reverse airflow, a Fresh Air breeze mode, light on/off with full-range dimming, and Correlated Color Temperature (CCT) Select for adjusting the light's color temperature (3000K/4000K/5000K) on compatible fans. On compatible fans it also unlocks Home Away simulated-occupancy mode.
The TR305 is not a universal ceiling-fan remote. Confirm that your original remote is marked TR305 and verify the installed receiver part number before ordering. Do not assume compatibility with TR305S, TR29S, TR205S, TR205DS, TR360, or other Fanimation remote-control systems.
Programming / Pairing Instructions
- Turn off power to the fan at the breaker (safety).
- Install/confirm the receiver in the hanger bracket per the fan's manual and remote control sheet (wiring from AC supply to receiver to fan motor/light).
- Restore power at the breaker.
- If your TR305/receiver has DIP switches, match the DIP switch positions on both units exactly, using a small screwdriver. Avoid leaving all switches "up" (factory default) to reduce interference.
- Within 30–60 seconds of restoring power, press and hold the SET/learn button on the remote for about 5–10 seconds (often accessed via a small hole or inside the battery compartment).
- Watch for confirmation: fan will blink, beep, or run briefly to indicate successful programming.
- After that, test fan speeds, reverse, Fresh Air mode, light on/off and dimming, CCT Select, and Home Away (if supported by your fan).
For installation, wiring, remote code setup, or compatibility questions, refer to the owner’s manual for the exact ceiling-fan model and receiver. For additional assistance, contact Fanimation Customer Care at 888-567-2055 or techsupport@fanimation.com.
Your satisfaction is one of our top goals here at Lighting & Bulbs Unlimited. We want you to shop confidently and know that we’ll help within reason to keep your purchase and shopping experience with us a smooth one. So let's be transparent about the return policy:
Eligible Returns
We accept returns when each of the following is checked:
- within 30 days of purchase with receipt,
- un-installed,
- not an item on our exclusions list, and
- in a re-sellable condition with all of its original packaging, documents, packaging fillers, and product parts.
We do not offer free return shipping at this time. Returns are subject to manufacturer restock fees (25% if refunded to your original payment method, or 10% if you exchange or opt in for showroom/website credit instead).
Exclusion List
The following items are final sale, and are therefore excluded from returns, exchanges, or alterations of any kind after sale:
- Display fixtures
• Clearance fixtures
• Custom-fixtures and/or those that are made-to-order
• Fixtures that have been installed or have had their wires cut, clipped or modified/used in anyway
• Services, and/or Labor charges
• Items missing their original packaging, handbooks, and other materials
• Replacement glass, parts, or shades
• Items not purchased from Lighting & Bulbs Unlimited
• Shipping/handling charges
• Gift cards/gift certificates and/or coupons used in the initial transaction
Services/Labor
Due to the nature of labor, services are not eligible for returns, exchanges, or post-sale alternations of any kind. If you experience an issue with a service, have a question or concern regarding it, please reach out and let us know. Lighting consultations that are eligible to use the consultation fee towards a purchase are only eligible to be used on product-purchases; not on any services or labor charges.
Restock Fees
Due to the logistics that manufacturers have set up, they charge 25% to restock their items to the warehouses. Therefore, orders are also subject to a restock fee of 25%. Item(s) being returned will be the total amount less any restock and original shipping charges, if any.
Store Credit, or Exchanges
To help with restock fees, we offer a 10% restock (as opposed to the 25%) if you choose to exchange your product or receive your refund through store credit. In the event that your refund is processed to provide you with store credit, please treat this store credit like cash as we are unable to replace store credit if lost or stolen.
Return Process
Ready to get your return started?
- Contact us immediately to avoid time delays that could affect your return or exchange eligibility. The sooner you reach out, the better the chances are that we’re able to help. If approved for an eligible return or exchange, we will inform you of the next steps.
- Include your order number on the shipment label or inside the box. Please do not write on any product packaging itself.
- Properly seal your box(es) and return them to the showroom. If you’re shipping your returns, please apply the shipping label in place of where the original label was, and ship them to the address below:
Lighting & Bulbs Unlimited
Attn: Returns
4335 Monroe Road
Charlotte, NC 28205
To help maintain your item’s new condition, please do not place your label anywhere other than where the original label was.
4. Returns are inspected upon arrival. Return credits or refunds to your original payment method are authorized after the item(s) have been returned and inspected by our receiving team, and usually take 1-5 business days to post to your account, depending on your bank/credit card company. If you have not received anything within 14-days of the date of delivery to our warehouse, please contact us so that we can look into it.
If your order has arrived in a damaged condition or doesn’t work properly immediately upon installation, please refer to the “Damaged & Defective Goods Policy”.
To read our full return policy, please visit it here.
We offer installation on everything we sell and more. From installing switch legs, junction boxes, dimmers, and more. When the fixtures, ceiling fans, under-cabinet lighting, or other products are purchased directly from us, the installation cost is lower.
